Cake Tray Forming Machine
JDGT Cake Tray Forming Machine
The cake tray forming machine is equipped with a mechanical hand to perform a series of tasks including, paper clipping, paper feeding, paper separating, punching and discharging, etc. Different sized cake trays can be formed by changing the molds. The auto temperature controller is designed to regulate the heating temperature. Our cake tray forming machine features simple structure, high efficiency, strong stability and easy manipulation.
Technical Specifications
| Model | JDGT |
| Paper Size | Ф55-Ф130mm |
| Raw Material | Oil-protect paper 30-40g/m2 |
| Capacity | 15-20 pcs/time 20-40 times/min. |
| Power Source | 380V/50Hz (it can be changed according to specific customer requirements) |
| Total Power | 2.5kW (Motor: 1.5kW Heating: 1 kW) |
| Air Source | Working pressure 0.6MPa Air volume 0.3m3/min |
| Weight | 500kg |
| Package Size | 1500×1300×1400mm |
Sini is a China cake tray forming machine manufacturer and supplier. We offer cake tray forming machine, and high speed paper cup machine, paper dish forming machine, paper bowl machine, high speed punching machine. Our high quality products are offered at competitive prices. Sini is located in China, and the full chain of manufacturing paper plate machine, paper cup sleeve machine can be completed in China, even in one city. Lower manufacturing cost saves your purchasing cost. The more details of each product are shown on the page with description.
-
